ModelPlan 270



Michael Adler's



The Connel Bridge





Completed in 1903, the Connel Bridge  near Oban in Northwest Scotland has a unique appearance because the main posts lean towards each other.



In the plan, how the bridge engineers reached this design is discussed in detail, and when the model is constructed, these features are fully revealed.



12 pages including text, photographs and parts list.



Ref:  MP270    Price:  6.90
