ModelPlan 249



Midlands Meccano Guild Model Series MMGMS7



Dragline



  A Set 10+ Model



Redesigned and Described by Roger Marriott



The well-known model of a Ransomes and Rapier W14 Walking Dragline on the covers of 1950's set manuals has been redesigned for building with a Set 10 plus a few extra parts.



Its five movements - walking, slewing, luffing, hoisting and dragging are controlled independently from one side of the model using two PDU motors via a simplified mechanism.



An improved main bearing, using Large Toothed Quadrants, provides smooth and realistic slewing.



28 pages including text, diagrams, colour photographs and parts list.



Ref:  MP249    Price:  9.60
