ModelPlan 204



Tony James'



Coles Hydra 10T Lorry-Mounted Crane



A Set 10 Model



This realistic 1:10 scale model has lever-operated boom hoisting,  slewing, derricking  and  telescoping powered by a Meccano PDU motor and cable-and-pulley simulated hydraulics, and also has working steering, suspension and hand-operated jacks.



To keep within the Set 10 limits, the road wheels are unpowered, but with some additional parts, a clutch, gearbox and differential can easily be incorporated.



24 pages including colour photographs and parts list, plus a separately-stapled  16-page booklet of diagrams.



Ref:  MP204    Price:  14.40
