ModelPlan 199



Tony James'



Van-mounted Access Platform

(Cherry Picker)





A Set 10 Model



Based on a real vehicle, the 1:10 scale model is powered by a Meccano PDU motor and has a clutch, suspension, gear lever, 2-speed and reverse gearbox, correctly-geared steering, a self-levelling, slewing man-basket hoist operated by cable-and-pulley simulated hydraulics, and power-operated stabilisers.



The van body conveniently slides off the chassis to provide access to the mechanisms



20 pages including colour photographs and parts list, plus a separately-stapled  12-page booklet of diagrams.



Ref:  MP199    Price:  9.90
