ModelPlan 174



John Ince's



The XY Meccanograph



◊  A Set 10+ Model  ◊



The basic feature of this Meccanograph is two cams, one which controls the pen arm in the transverse (X) direction and the other in the longitudinal (Y) direction, enabling the pen to draw "figure of eight" patterns.



A ratchet mechanism under the designing table allows the machine to draw either continuous or intermittent patterns, and the Meccanograph can be motorised or hand-driven.



Ref:  MP174  12 Pages   Price:  6.00
